Extra Long Solid Carbide Drills For MQL Systems
Features and Benefits
- Advanced M.Q.L. delivery system for extra-long solid carbide drills
- Decreased friction resulting in increased tool life with M.Q.L.
- Strong cutting edges of drill resist chipping and breakage resulting in increased productivity
- Wide flute design and lapping on the flute for smooth chip evacuation
- Ultra-fine substrate with TiAlN coating for a high level of wear-resistance and toughness
- Complete range of 10XD, 15XD, and 20XD drills that are also available with M.Q.L. design
Product Ranges & Details
Series: DRXL 10:1
Shank Dia. Range: 4mm-10mm
Drill Dia. Range: 4mm-10mm
Max DOC Range: 50mm-122mm
Overall Length Range: 105mm-190mm
Series: DRXL 15:1
Shank Dia. Range: 4mm-10mm
Drill Dia. Range: 4mm-10mm
Max DOC Range: 70mm-172mm
Overall Length Range: 125mm-240mm
Series: DRXL 20:1
Shank Dia. Range (inch): .2500–.3750"
Shank Dia. Range (metric): 4mm–10mm
Drill Dia. Range (inch): .2500–.3750"
Drill Dia. Range (metric): 4mm–10mm
Max DOC Range (inch): 5.00–7.50"
Max DOC Range (metric): 85mm-217mm
Overall Length Range (inch): 7.87–10.82"
Overall Length Range (metric): 140mm-285mm
Materials:
Cast Iron
Steel
Stainless Steel
Hardened Steel
