Series: CGM313R - 11mm Inserts
Representative image shown ⓘ
The image above is intended to represent the product series for illustrative purposes only. The actual product may vary.
Product Series Features:
- Tangential Inserts with 4 Cutting Edges
- RH Inserts
- Metric Sizes: 11 mm
Part Number |
Application |
RE Corner Radius |
BS Wiper Length |
INSL Insert Length |
W1 Insert Width |
S Thickness |
NOI Number of Indexes |
IH Insert Hand |
|
|---|---|---|---|---|---|---|---|---|---|
| CGM313R001-M | Standard | 0.031 | 0.079 | 0.433 | 0.436 | 0.236 | 4 | Right | |
| CGM313R001-ML | Stainless & Exotics | 0.031 | 0.079 | 0.433 | 0.436 | 0.236 | 4 | Right | |
| CGM313R001-MLP | Sharp & Polished | 0.031 | 0.079 | 0.433 | 0.436 | 0.236 | - | Right | |
| CGM313R002-M | Standard | 0.062 | 0.047 | 0.433 | 0.436 | 0.236 | 4 | Right | |
| CGM313R002-ML | Stainless & Exotics | 0.062 | 0.047 | 0.433 | 0.436 | 0.236 | 4 | Right | |
| CGM313R004-M | Standard | 0.125 | - | 0.433 | 0.409 | 0.236 | 4 | Right |
Notes:
- *Images are a representation of the product series and therefore may not be an exact representation of the specific item
- **IN2536 grade will be available when all INxx35 grade inserts have been depleted from stock**
