Series: 16W7B, 26W1B, 16W7J, 26W1L
Representative image shown ⓘ
The image above is intended to represent the product series for illustrative purposes only. The actual product may vary.
Product Series Features:
- Two-Effective Ball Nose End Mill
- Cutting edge length: 1.06" to 3.65"
EDP |
Part Number |
DC Cutting Dia. |
APMX Depth of Cut Max. |
LUX Usable Length Max. |
LPR Protruding Length |
OAL Overall Length |
ZNF Face Insert Count |
ZNP Peripheral Insert Count |
NOF Number of Flutes |
PRFRAD Profile Radius |
DCON Shank Dia. |
CSP Coolant |
DXF File |
STEP Light File |
STEP Detailed File |
|
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 3000295 | 16W7J-2004082R02 | 2.000 | 1.620 | - | 4.00 | 7.25 | 4 | 4 | - | - | 2.000 | No | NA |
